Forged High Pressure Pipe Fittings

Summary
Type	Elbow, Tee, Cross, Coupling, Half Coupling, Cap, Plug, Bushing, Union, HEX. Nipple, Swage nipple, Bull Plug, Street Elbow, Boss, Reducer Insert and Out-let…etc Threaded (NPT or PT Type), Socket-Weld, Butt-welding
Size	NPS 1/8”~4” DN 6~100
Rating Pressure	Threaded End – 2000 / 3000 / 6000 LBS. Socket-weld End – 3000 / 6000 / 9000 LBS. Butt-weld End – SCH40 / SCH80 / SCH160 / XXS
Specification	Dim. Spec. : ASME B16.11-2009 (Revision of ASME B16.11-2005) MSS – SP – 79, 83, 95, 97 and BS3799. ANSI / ASME B1.20.1-1983 NPT Material Spec. : ASTM A105, A350 LF2, A106, A312, A234, A403 ASTM A182 (F304, F304L, F316, F316L, F304H, F316H, F317L, F321, F11, F22, F91) Size of Raw Material: DIA. 19~85mm Round Bar.
Marking	Carbon and Alloy Steel: Marked by stamping. Stainless Steel: Marked by electro-etched, jet printed or stamping. 3/8” under: Brand only. 1/2” to 4”: Marked with brand, material, heat code, B16 (For ASME B16.11 product), pressure and size.
Finishing	Carbon steel: Galvanized or black. Stainless steel: Pickled.
